Расширители лопастные: тип РЛ и ПЗУ-280

Replaceable blades are easy to replace in rig conditions, reducing tool operating costs

Sets of anti-sidetracking devices with replaceable nozzles for reaming previously drilled intervals

Launch video

Blade reamers RL are designed for drilling wells with a pilot bit or reaming previously drilled intervals. The service life of reamers is not inferior to that of PDC bits under similar conditions, thereat reaming is performed at high ROP. The reamer blades equipped with PDC cutting structure have back reaming cutters and reinforced gage protection.

Reamers are equipped with replaceable blades that can be easily replaced in drilling conditions, which significantly reduces the operating costs for repair and maintenance of the tool.

For efficient cuttings transportation reamers are equipped with replaceable wear-resistant hydraulic nozzles.

To ream previously drilled intervals of the wellbore the reamer can be equipped with an extension sub and an anti-sidetracking device (PZY) equipped with six interchangeable nozzles, five of which are directed upwards, one downwards.

Blade reamer RL

PZY-280

Size	Body OD, mm	Pilot hole min diameter (pilot bit), mm	Max reaming diameter, mm	Length, mm	Tool joint per GOST 28487-90
RL-152-215,9	152	152,4	215,9	550	Z-102/З-88
RL-216-295,3	235	215,9	295,3	780	Z-117/З-117
RL-216-311	235	215,9	311	780	Z-117/З-117
RL-295-394	310	295,3	394	980	Z-147/З-152 Z-171/З-152 Z-171/З-171
RL-295-398	310	295,3	398	980	Z-147/З-152 Z-171/З-152 Z-171/З-171
RL-295-444,5	310	295,3	444,5	980	Z-147/З-152 Z-171/З-152 Z-171/З-171
RL-295-495	350	295,3	495	1000	Z-147/З-152 Z-171/З-152 Z-171/З-171
RL-295-510	350	295,3	510	1000	Z-147/З-152 Z-171/З-152 Z-171/З-171
RL-295-550	350	295,3	550	1000	Z-147/З-152 Z-171/З-152 Z-171/З-171
RL-295-585	350	295,3	585	1000	Z-147/З-152 Z-171/З-152 Z-171/З-171
RL-394-660,4	394	393,7	660,4	1000	Z-171/З-171
RL-394-710	394	393,7	710	1000	Z-171/З-171

To ream previously drilled intervals of the wellbore the reamer can be equipped with an extension sub and an anti-sidetracking device (PZY) equipped with interchangeable nozzles.

PZY type	Reamer sizes
PZY-140	RL-152-215,9
PZY-200	RL-216-295,3 RL-216-311
PZY-280	RL-295-394 RL-295-398 RL-295-444,5 RL-295-495 RL-295-510 RL-295-550 RL-295-585
PZY-350	RL-394-660,4 RL-394-710
